1
MHT CET 2025 26th April Morning Shift
MCQ (Single Correct Answer)
+1
-0
When a resistance of $100 \Omega$ is connected in series with a galvanometer of resistance ' G ', its range is ' $V$ '. To double its range, a resistance of $1000 \Omega$ is connected in series. The value of ' $G$ ' is
A
$400 \Omega$
B
$800 \Omega$
C
$1000 \Omega$
D
$1200 \Omega$
2
MHT CET 2025 26th April Morning Shift
MCQ (Single Correct Answer)
+1
-0

The potentiometer wire is 5 m long and potential difference of 4 V is maintained between the ends. The e.m.f. of the cell which balances against a length of 200 cm of the potentiometer wire is

A
0.4 V
B
0.8 V
C
1.2 V
D
1.6 V
3
MHT CET 2025 25th April Evening Shift
MCQ (Single Correct Answer)
+1
-0

Two batteries of e.m.f 4 V and 8 V with internal resistance $1 \Omega$ and $2 \Omega$ respectively are connected in a circuit with a resistance of $9 \Omega$ as shown in the figure. The current and potential difference between the points ' P ' and ' Q ' is $\mathrm{R}=9 \Omega$

MHT CET 2025 25th April Evening Shift Physics - Current Electricity Question 1 English
A
$\frac{1}{3} \mathrm{~A}$ and 4 V
B
$\frac{1}{3}$ A and 3 V
C
$\frac{1}{2}$ A and 5 V
D
$\frac{1}{6} \mathrm{~A}$ and 3 V
4
MHT CET 2025 25th April Evening Shift
MCQ (Single Correct Answer)
+1
-0

With a resistance ' X ' connected in series with a galvanometer of resistance $100 \Omega$, it acts as a voltmeter of range $0-15 \mathrm{~V}$. To double the range, a resistance of $1500 \Omega$ is to be connected in series with ' X '. The value of ' X ' in ohm is

A
900
B
1100
C
1400
D
1600
