A three phase 415 V, 50 Hz, 6-pole, 960 RPM, 4 HP squirrel cage induction motor drives a constant torque load at rated speed operating from rated supply and delivering rated output. If the supply voltage and frequency are reduced by 20%, the resultant speed of the motor in RPM (neglecting the stator leakage impedance and rotational losses) is ___________ (Round off to the nearest integer).
A 4-pole induction motor with inertia of 0.1 kg-m2 drives a constant load torque of 2 Nm. The speed of the motor is increased linearly from 1000 rpm to 1500 rpm in 4 seconds as shown in the figure below. Neglect losses in the motor. The energy, in joules, consumed by the motor during the speed change is _________. (round off to nearest integer).
A 3-phase, 415 V, 50 Hz induction motor draws 5 times the rated current at rated voltage at starting. It is required to bring down the starting current from the supply to 2 times of the rated current using a 3-phase autotransformer. If the magnetizing impedance of the induction motor and no load current of the autotransformer is neglected, then the transformation ratio of the autotransformer is given by ________. (round off to two decimal places).
R1 = R2' = Xl1 = Xl2' = 12 $$\Omega $$, Xm = 240 $$\Omega $$
and s is the slip. At no-load, the motor speed can be approximated to be the synchronous speed. The no-load lagging power factor of the motor is___________ (up to 3 decimal places).
![GATE EE 2018 Electrical Machines - Induction Machines Question 9 English](https://imagex.cdn.examgoal.net/AIHbF2FK0EqqvYnQj/ju3IWB9KEM7bRbZXMbotRPoSXALlk/BNR9jn6DRhqfOr0RfQjGqS/uploadfile.jpg)
