A 3-phase, $400 \mathrm{~V}, 4$ pole, 50 Hz star connected induction motor has the following parameters referred to the stator :

$$ R_r^{\prime}=1 \Omega, X_S=X_r^{\prime}=2 \Omega $$

Stator resistance, magnetizing reactance and core loss of the motor are neglected. The motor is run with constant V/f control from a drive. For maximum starting torque, the voltage and frequency output, respectively, from the drive, is closest to,

Which one of the following figures represents the radial electric field distribution $E_R$ caused by a spherical cloud of electrons with a volume charge density. $\rho=-3 \rho_0$ for $0 \leq R \leq a$ (both $\rho_0, a$ are positive and $R$ is the radial distance) and $\rho=0$ for $R>a$ ?

An air filled cylindrical capacitor (capacitance $C_0$ ) of length $L$, with $a$ and $b$ as its inner and outer radii, respectively, consists of two coaxial conducting surfaces. Its crosssectional view is shown in Figure (i). In order to increase the capacitance, a dielectric material of relative permittivity $\varepsilon_r$ is inserted inside $50 \%$ of the annular region as shown in figure (ii). The value of $\varepsilon_r$ for which the capacitance of the capacitor in figure (ii), becomes $5 C_0$ is
